Leica Stellaris 5 Laser Scanner Confocal w/ DMI8 Inverted Phase Contrast Fluorescence with AFC Confocal

Leica Stellaris 5 Confocal with DMi8 Inverted Fluorescence Trinocular Microscope with AFC (Used)

The Leica Stellaris 5 Confocal system, paired with the DMi8 Inverted Phase Contrast Fluorescence Microscope, delivers high-performance imaging for advanced research applications. Featuring high-sensitivity Power HyD S hybrid detectors, Adaptive Focus Control (AFC), and a comprehensive set of laser lines, this system is optimized for live-cell imaging, fluorescence microscopy, and confocal applications.

Condition

Condition: Refurbished/Used

This system was recently decommissioned, professionally serviced, and received preventative maintenance from Leica. It is currently crated and ready for shipment. Installation by Leica will be required at the destination site, at which point the system will be eligible for a new Leica service contract.

Included Items

• Leica Stellaris 5 LIAchroic System (Part #: 158101101)
• FOV Scanner for Stellaris 5 (Part #: 158101130)
• RGB LIAchroic Dichroic Filters (Part #: 158209433)
• Fluorifier Disc Basis with Analyzer (Part #: 158204510)
• Notch Filter Set for Visible Spectrum (Part #: 158204511)
• Scan Optics HIVISR for DMi8 (Part #: 158101121)
• Power HyD S 2-Channel SP Core Unit (Part #: 158101312)
• SP Light Traps (3x) (Part #: 158201310)
• Stellaris 5 DMi8 Adapter (Part #: 158101140)
• Solid State Laser Launch with Lasers:
  • 405nm (UV) (Part #: 158202140)
  • 488nm (Blue) (Part #: 158202112)
  • 561nm (Green) (Part #: 158202114)
  • 638nm (Red) (Part #: 158202115)
• Leica DMi8 Inverted Phase Contrast Fluorescence Microscope with Adaptive Focus Control (AFC)
• Nosepiece: 6-Position Motorized Coded Nosepiece
• (3) Filter Cubes of your choice (Additional Cubes Available for purchase)
• Computer & Software:
  • Workstation Select for Imaging Processing (Part #: 158203111)
  • Monitor
  • LAS X Stellaris Control Software (Part #: 158203200)
  • LAS X 3D Visualization (Part #: 158203202)
  • LAS X Dye Finder (Part #: 158203206)
  • LAS X Assay Editor (Part #: 158203211)

Available Options

• Objectives (Please discuss your application or preferred configuration with our team. We have a full suite of options available.)
• Stage: Motorized and Manual options available
• Okolab Incubation System: Transparent Box Incubator for DMi8, K-Frame Sample Chamber, CO₂ and Humidity Control
• Optical Table: New and Refurbished options available

Illuminator (Choose One):

• 100w Mercury w/ Power Supply
• Upgrade to: Used Metal Halide
• Upgrade to: New X-Cite 110LED System with Adapter. Includes: X-Cite 110LED, speedDIAL remote, 3mm x 1500mm Liquid Light Guide
• Upgrade to: New X-Cite mini+ System. Includes: LED head, miniCUBE controller, speedDIAL remote, Microscope Coupling Flange
• Upgrade to: New X-Cite XYLIS II, XT730S w/1.5m LLG. Includes: X-Cite XYLIS (XT720S), speedDIAL remote, 3mm x 1500mm Liquid Light Guide

Key Features

• Confocal Imaging: High-resolution confocal microscopy with the Leica Stellaris 5 system for clear, detailed images.
• Adaptive Focus Control (AFC): Maintains sharp focus over extended periods, crucial for live-cell studies.
• Hybrid Detector (HyD) Technology: Power HyD S detectors deliver high sensitivity and low noise for high-contrast fluorescence imaging.
• Broad Laser Spectrum: 405nm, 488nm, 561nm, and 638nm lines for multi-channel fluorescence applications.
• Fluorescence & Phase Contrast: Combines confocal fluorescence with phase contrast for enhanced cellular visualization.
• Inverted Microscope Design: Ideal for live-cell imaging and long-term time-lapse studies.
• Optional Environmental Control: Okolab incubation with CO₂ and humidity control available for live-cell experiments.
• Optional Motorized Scanning Stage: Precision movement for tile scanning and multi-position imaging.
• Fully Integrated Workstation: LAS X Stellaris software for acquisition, data analysis, 3D visualization, and dye selection.
• Optional Optical Table: New and refurbished vibration isolation tables available for ultra-stable imaging.

Applications

• Live-cell imaging & time-lapse studies
• Multi-channel fluorescence imaging
• Super-resolution microscopy
• 3D visualization & volumetric imaging
• Colocalization & FRET analysis
• FRAP & ROI-guided photostimulation
• Z-stack imaging & deconvolution
• High-content screening
• Fluorescence lifetime imaging (FLIM)
• Drug discovery & cell signaling research

Specifications

Configuration shown is for demonstration purposes. Contact us to discuss your application and needs for a customized quote.
