Leica DMIL LED Cell Factory Inverted Trinocular Phase Contrast Fluorescence Microscope.

Leica DMIL LED Inverted Fluorescence Microscope – Trinocular Fluorescence Version with Flat Stage

The Leica DMIL LED Fluorescence Microscope is a robust, compact inverted microscope tailored for routine fluorescence, phase contrast, and transmitted light applications in cell culture and research environments. Outfitted with a trinocular viewing head and a flat stage, this configuration is optimized for simple, efficient inspection of flasks, dishes, and multi-well plates—particularly in laminar flow hoods, incubators, or teaching setups.

This model delivers bright, stable LED illumination for both transmitted and fluorescence imaging and supports Leica’s infinity-corrected optical system. It’s ideal for labs performing routine fluorescent staining, live-cell assessments, or basic phase contrast workflows.

Condition

Refurbished/Used
This microscope has been tested and verified to meet manufacturer specifications.

Included Items

• Leica DMIL LED Microscope Body (Inverted)
• Trinocular Viewing Head – For ergonomic viewing and camera integration
• Widefield Eyepieces
• Manual Fluorescence Filter Cube Turret
• (3) Fluorescence Filter Cubes of Your Choice (Additional cubes available)
• Manual Condenser – For brightfield and phase contrast
• Manual 4-Position Nosepiece
• Flat Stage – Ideal for use with flasks, dishes, and well plates
• Integrated Transmitted LED Illumination Module
• Fluorescence LED Light Source
• Power Supply and Cabling

Key Features

• Compact inverted frame optimized for routine fluorescence and phase imaging
• Long-life LED illumination (transmitted and fluorescence)
• Manual cube turret with 3-position fluorescence support
• Flat stage for fast sample access – ideal for multi-well plates and dishes
• Brightfield and phase contrast capability with included condenser
• Trinocular head allows for live viewing and digital capture
• Excellent optical clarity for basic to mid-level fluorescence workflows

Applications

• Routine Fluorescence Imaging
• Cell Culture Quality Control
• Basic Phase Contrast Observation
• Immunofluorescence (DAPI, FITC, TRITC)
• Clinical, IVF, Biotech, and Academic Lab Use

Specifications

Feature	Specification
Microscope Type	Inverted Fluorescence & Phase Contrast
Viewing Head	Trinocular
Illumination	Integrated LED (Brightfield) + LED Fluorescence Source
Filter Cube Turret	Manual (3-position)
Filter Cubes Included	(3) of User’s Choice
Nosepiece	Manual, 4-position
Condenser	Manual (Brightfield and Phase Compatible)
Focus Mechanism	Manual Coarse and Fine Focus
Stage	Flat Stage (non-mechanical)
Camera Port	Left-Side C-Mount
Software	Not required

Illuminator Options

• Standard LED Fluorescence Light Source (Included)
• Upgrade Options:
  • X-Cite 110LED System
  • X-Cite Mini+ System
  • X-Cite XYLIS II System

Objectives

Please consult with our team to configure Leica-compatible Plan Achromat and Phase contrast objectives tailored to your application.

Stage

Flat stage included. Optional mechanical stage upgrade available.

(3) Fluorescence Filter Cubes of Your Choice

Additional filter cubes available for purchase.

Configuration shown is for demonstration purposes. Contact us to discuss your application and needs for a customized quote.
