Okolab H601‑K‑FRAME‑GLASS‑FLAT ITO Glass Plate with Heated Frame | Flat Ø160×110 mm K‑Frame Stage Insert

The Okolab H601‑K‑FRAME‑GLASS‑FLAT is a flat, precision-heated ITO glass plate integrated into a sturdy aluminum frame, designed to sit flush with 160×110 mm K‑frame XY stage inserts (Marzhauser, Ludl, ASI, Prior H107/H117, Leica, Zeiss, Olympus). It delivers uniform, transparent heating while maintaining the classic focal plane.

Condition

Condition: New with Manufacturer Warranty

Included Items

• One H601‑K‑FRAME‑GLASS‑FLAT ITO glass heating plate (factory-sealed, brand new)

Key Features

• Flush-mounted flush with K‑frame inserts (160×110 mm) without changing focal height :contentReference[oaicite:1]{index=1}
• Surface-accurate heating (ambient to 60 °C); ± 0.3 °C specimen accuracy via integrated surface sensor :contentReference[oaicite:2]{index=2}
• ITO-coated Dragontrail™ glass (0.5 mm thick), chemically strengthened and anti-scratch, anti-fingerprint :contentReference[oaicite:3]{index=3}
• Raises focal plane by approximately +7.5 mm (+10 mm on Prior H117) :contentReference[oaicite:4]{index=4}
• Durable aluminum frame with 10-year warranty against glass damage :contentReference[oaicite:5]{index=5}
• Compatible with H401‑T‑CONTROLLER (dual-channel touchscreen) or H401‑T‑PENNY single-channel controller :contentReference[oaicite:6]{index=6}

Applications

• Live-cell or time-lapse imaging on K‑frame inverted microscopes
• Oil-immersion and high-resolution microscopy with stable thermal environment
• Perfusion, IVF, and environmental control workflows requiring optical transparency

Specifications

Configuration shown is for demonstration purposes. Contact us to discuss your application and needs for a customized quote.
