Okolab Warm metal plate for Prior H117 - Recessed Environmental Control

Okolab H401‑PRIOR‑H117‑METAL‑RECESSED Warm Metal Plate | Recessed Insert for Prior H117 Stage

The Okolab H401‑PRIOR‑H117‑METAL‑RECESSED is a precision-engineered heated metal T-plate designed specifically for the Prior H117 microscope stage. Its recessed profile maintains the original focal plane while delivering rapid, uniform thermal control—ideal for live-cell, time-lapse, and high-resolution imaging.

Condition

Condition: New with Manufacturer Warranty

Included Items

• One H401‑PRIOR‑H117‑METAL‑RECESSED heated metal plate (factory sealed, brand new)

Key Features

• Flush with XY stage on Prior H117 microscopes—maintains original focal plane :contentReference[oaicite:0]{index=0}
• Recessed design; raises focal plane by only +1.5 mm :contentReference[oaicite:1]{index=1}
• Operating range: ambient up to 60 °C with ±0.3 °C specimen accuracy :contentReference[oaicite:2]{index=2}
• Circular observation window (Ø 24 mm); compatible with oil-immersion objectives :contentReference[oaicite:3]{index=3}
• Surface-mounted sensor ensures accurate temperature control and uniform heating
• Quick and tool-free plate replacement
• Requires H401‑T‑CONTROLLER (dual-channel) or compact H401‑T‑PENNY (single-channel) for operation

Applications

• Live-cell and time-lapse microscopy on Prior H117 inverted systems
• High-resolution imaging with oil-immersion objectives
• Perfusion, CO₂/O₂ control, and other environmental microscopy workflows

Specifications

Configuration shown is for demonstration purposes. Contact us to discuss your application and needs for a customized quote.
