Okolab H401‑K‑FRAME‑METAL‑RECESSED Warm Metal Plate | Recessed 160 × 110 mm K-Frame Stage Insert

The Okolab H401‑K‑FRAME‑METAL‑RECESSED is a precision-engineered heated metal plate designed for inverted microscopes using 160 × 110 mm K-frame format stages. It provides recessed, temperature-controlled support to maintain the native focal plane while offering fast, uniform sample heating—ideal for live-cell, time-lapse, and high-resolution imaging.

Condition

Condition: New with Manufacturer Warranty

Included Items

• One H401‑K‑FRAME‑METAL‑RECESSED heated metal plate (factory-sealed, brand new)

Key Features

• Recessed design (‑5.0 mm) maintains original focal plane; raises plate by +2.5 mm above stage surface :contentReference[oaicite:0]{index=0}
• Temperature control from ambient to 60 °C with ±0.3 °C specimen accuracy :contentReference[oaicite:1]{index=1}
• Circular observation window (Ø 24 mm) compatible with oil-immersion objectives :contentReference[oaicite:2]{index=2}
• Compatible with common K-frame stages (Marzhauser, Ludl, ASI, Leica, Zeiss, Olympus, Prior H107/H117) :contentReference[oaicite:3]{index=3}
• Precision surface sensor ensures even heating and reproducible thermal performance
• Quick, tool-free replacement when needed
• Requires H401‑T‑CONTROLLER or H401‑T‑PENNY temperature controller

Applications

• Live-cell and time-lapse imaging on inverted microscopes with K-frame stages
• Oil-immersion microscopy requiring stable thermal conditions
• Environmental control for perfusion, CO₂/O₂, or cold chamber applications

Specifications

Configuration shown is for demonstration purposes. Contact us to discuss your application and needs for a customized quote.
