PCO pco.dicam C1 LX 25-S20-P46 SEL 4.2MP Monochrome Intensified sCMOS Microscope Camera

PCO pco.dicam C1 LX 25-S20-P46 SEL – 4.2 Megapixels Monochrome Intensified sCMOS Camera – 85108001019

The PCO pco.dicam C1 LX 25-S20-P46 SEL is a high-resolution intensified sCMOS camera system combining a 4.2 megapixel scientific CMOS sensor (2048 x 2048) with a 25 mm image intensifier. Engineered for ultra-low light detection and fast time-resolved imaging, it features sub-nanosecond gating, high quantum efficiency, and low noise, making it an ideal solution for fluorescence lifetime imaging, plasma studies, and laser-induced phenomena.

Condition

New with Manufacturer Warranty

Included Items

• PCO pco.dicam C1 LX Camera Head with 25 mm Image Intensifier
• Gating Controller and Cables
• Power Supply
• PCO Software Suite and Drivers

Key Features

• 4.2 Megapixel sCMOS sensor (2048 x 2048 resolution)
• 25 mm image intensifier with S20 photocathode and P46 phosphor
• Sub-nanosecond gating (SEL = Selected ultra-fast gate model)
• High QE and low read noise for single-photon detection
• Compatible with fluorescence lifetime, LIF, and other time-gated techniques

Applications

• Time-Resolved Fluorescence and Phosphorescence Imaging
• Single-Photon and Low-Light Detection
• Laser-Induced Fluorescence (LIF)
• Combustion and Plasma Diagnostics
• High-Speed, Gated Imaging in Biophysics and Photonics

Specifications
