PCO pco.dicam C1 UHS 18-S20-P43 SEL 1.5MP Monochrome Intensified sCMOS Microscope Camera

PCO pco.dicam C1 UHS 18-S20-P43 SEL – 1.5 Megapixels Monochrome Intensified sCMOS Camera – 85108001054

The PCO pco.dicam C1 UHS 18-S20-P43 SEL is an ultra-high-speed intensified sCMOS camera optimized for nanosecond gating and extreme low-light detection. It features a 1.5 megapixel sCMOS sensor (1280 x 1024), paired with an 18 mm image intensifier using an S20 photocathode and fast-decay P43 phosphor. The SEL configuration enables sub-nanosecond gating, ideal for cutting-edge time-resolved imaging in physics, biology, and combustion diagnostics.

Condition

New with Manufacturer Warranty

Included Items

• PCO pco.dicam C1 UHS Camera Head with 18 mm S20/P43 Image Intensifier
• Sub-nanosecond Gating Control Electronics (SEL)
• Power Supply
• PCO Software & Drivers

Key Features

• 1.5 Megapixel sCMOS sensor (1280 x 1024 resolution)
• 18 mm image intensifier with S20 photocathode
• P43 phosphor for fast decay and minimal image lag
• Sub-nanosecond gating with high timing precision
• Designed for extreme-speed and ultra-low light environments

Applications

• Laser-Induced Fluorescence (LIF)
• Plasma and Combustion Diagnostics
• Time-Resolved and Gated Imaging
• Single-Photon Detection and Biophotonics
• Ultrafast Dynamics and Shockwave Analysis

Specifications
