PCO UMM-SFG Reference Slide – Green Fluorescence Lifetime Standard – 50202500021
The PCO UMM-SFG is a precision reference slide designed for validating and calibrating fluorescence lifetime imaging (FLIM) systems in the green spectral range. Optimized for use with PCO's pco.flim X and LED/laser excitation sources, this slide provides a reproducible lifetime signal for benchmarking system performance and ensuring consistent quantitative results in biomedical and biophysical fluorescence experiments.
Condition
New with Manufacturer Warranty
Included Items
- PCO UMM-SFG Reference Slide (Green)
- Protective Storage Case
- Factory Lifetime Reference Documentation (if supplied)
Key Features
- Stable, repeatable fluorescence lifetime in the green range (e.g., ~510–550 nm emission)
- Optimized for green excitation sources such as 488 nm and 515 nm lasers or LEDs
- Ideal for FLIM calibration, validation, and quality control
- Compatible with both frequency-domain and time-domain systems
Applications
- FD-FLIM and TD-FLIM System Calibration
- Lifetime Measurement Benchmarking
- Instrument Drift Monitoring
- Training and Demonstration Samples
- Quantitative Fluorescence Imaging Validation
Specifications
| Specification | Detail |
|---|---|
| Model | UMM-SFG |
| Fluorescence Range | Green (Emission peak ~530 nm) |
| Excitation Compatibility | 488 nm, 515 nm |
| Use Case | FLIM Calibration & Quality Control |
| Form Factor | Standard Microscope Slide Format |
| Part Number | 50202500021 |
Additional discounts may apply. Contact us for a quote.
Additional Details
Additional Details
- Manufacturer: PCO
- Model:
- Catalog Number: PCO-50202500021
- Serial Number:
- Condition: New
