SKU: PRODUCT ID:1T-01-IRIS-9-PCIE-M-16-C

Teledyne Photometrics Iris 9 PCI-E 9MP Monochrome sCMOS Microscope Camera

Teledyne Photometrics Iris 9 PCI-E 9MP Monochrome sCMOS Microscope Camera

Regular price $12,000.00 USD
Regular price Sale price $12,000.00 USD
Sale Sold out
Shipping calculated at checkout.

This is the Teledyne Photometrics manufacturer list price.

Additional discounts may apply. Contact us for potential discount pricing and your exact quote.

Call (877) 564-2767 or email sales@coastalmicroscopes.com

  • ✓ New, with the full manufacturer warranty
  • ✓ Typical delivery in 1 to 3 weeks, depending on parts
  • ✓ Prices shown exclude freight, insurance, tariffs and applicable taxes
  • ✓ Installation, training and service available from our engineers (quoted separately)
  • ✓ SAM.gov registered (CAGE 10ZU5). Purchase orders welcome
  • ✓ Leasing and finance companies available

Questions? Call (877) 564-2767 or email sales@coastalmicroscopes.com

Teledyne Photometrics Iris 9 PCIe 9MP Monochrome sCMOS Camera

The Teledyne Photometrics Iris 9 is a high-resolution sCMOS camera with small 4.25 µm pixels over a 17.8 mm diagonal, designed to capture fine detail with lower-magnification objectives and to cover large samples in fewer tiles. This version connects over PCI Express.

Condition

New with Manufacturer Warranty

Included Items

  • Iris camera (monochrome)
  • PCI Express interface card
  • PCI Express data cable
  • Trigger cable
  • Power supply
  • PVCAM drivers and quick start guide

Key Features

  • 2960 x 2960 sCMOS array, 8.7 MP
  • Small 4.25 µm pixels for high spatial resolution at low magnification
  • 17.8 mm diagonal field of view
  • 1.5 e- median read noise, 73% peak QE
  • 30 fps full frame over PCIe
  • Pattern noise and correlated noise reduction for clean backgrounds
  • Programmable Scan Mode for light sheet synchronization (PCIe)
  • Compact 76 x 76 x 88 mm body

Applications

  • Tile and stitch imaging of tissue sections and whole slides
  • Light sheet microscopy
  • Live-cell fluorescence at low magnification
  • Calcium imaging
  • Large-sample and organism imaging

Specifications

Manufacturer Teledyne Photometrics
Model Iris 9 (PCIe)
Catalog number 01-IRIS-9-PCIE-M-16-C
Sensor GPixel GSENSE5130 sCMOS
Active array 2960 x 2960 (8.7 MP)
Pixel size 4.25 x 4.25 µm
Sensor area 12.6 x 12.6 mm (17.8 mm diagonal)
Peak QE 73%
Read noise 1.5 e- (median)
Full well 10,000 e-
Full-frame rate 30 fps (16-bit)
Readout Rolling shutter
Cooling Forced air
Interface PCI Express
Lens mount C-mount
Dimensions 76 x 76 x 88 mm

Additional tariffs may apply.

Additional discounts may apply. Contact us for a quote.

Additional Details

  • Manufacturer: Teledyne Photometrics
  • Model: Iris 9 PCI-E 9MP Monochrome sCMOS (PCIE)
  • Catalog Number: 1T-01-IRIS-9-PCIE-M-16-C
  • Serial Number: N/A
  • Condition: New
