PRODUCT ID:Aries6506

Tucsen Aries 6506 5.7MP Monochrome Cooled sCMOS Microscope Camera

Tucsen Aries 6506 5.7MP Monochrome Cooled sCMOS Microscope Camera

$16,950.00 USD
$16,950.00 USD
Sale Sold out
Shipping calculated at checkout.

Tucsen Aries 6506 Monochrome Cooled BSI sCMOS Camera – 95% QE, 0.7e⁻ Read Noise, 2x10G GigE

The Tucsen Aries 6506 is a high-performance backside-illuminated (BSI) sCMOS camera engineered for advanced fluorescence microscopy, live-cell imaging, and quantitative scientific research. Featuring 95% peak quantum efficiency, ultra-low read noise down to 0.7 e⁻, and a large 22 mm diagonal sensor, this camera delivers exceptional sensitivity, speed, and dynamic range for demanding imaging applications.

Condition

New with Manufacturer Warranty

Included Items

  • Tucsen Aries 6506 Monochrome Cooled sCMOS Camera (C Mount)
  • USB 3.0 Cable
  • External Power Supply
  • Camera Control Software & SDK Package
  • Driver Package
  • Digital User Manual
  • Trigger Cable
  • C-Mount Dust Cap

Key Features

  • Backside-Illuminated (BSI) sCMOS sensor
  • 95% peak quantum efficiency for fluorescence imaging
  • Ultra-low read noise down to 0.7 e⁻
  • 2400 × 2400 resolution with 6.5 μm pixels
  • Multiple readout modes: HDR, Speed, Sensitivity, Super Sensitivity
  • High frame rates up to 200 fps
  • FPGA binning: 2 × 2 and 4 × 4
  • DPC image correction
  • Dual 10G GigE data interface
  • Hardware and software trigger support
  • Air or liquid cooling capability
  • C Mount optical interface

Applications

  • Fluorescence microscopy
  • Live-cell imaging
  • Low-light scientific imaging
  • Calcium imaging
  • High-speed biological dynamics
  • Quantitative research imaging
  • Confocal and widefield microscopy

Specifications

Model: Aries 6506
Sensor Type: BSI sCMOS
Sensor Model: Gpixel GSENSE 6510BSI
Peak QE: 95%
Color/Mono: Mono
Array Diagonal: 22 mm
Effective Area: 15.7 mm x 15.7 mm
Resolution: 2400 (H) x 2400 (V)
Pixel Size: 6.5 μm x 6.5 μm
Readout Mode: HDR, Speed, Sensitivity, Super sensitivity
Bit Depth: 16 bit, 11 bit, 12 bit
Frame Rate: 111 fps @ 16 bit HDR mode

200 fps @ 11 bit Speed mode

117 fps @ 12 bit Sensitivity mode

6.9 fps @ 12 bit Super sensitivity mode
Readout Noise: 1.6 e- @ 16 bit HDR mode

2.0 e- @ 11 bit Speed mode

1.2 e- @ 12 bit Sensitivity mode

0.7 e- @ 12 bit Super sensitivity mode
Dark Current @ 0°C: 0.5 e-/p/s @ 16 bit HDR mode

1 e-/p/s @ 11 bit Speed mode

0.5 e-/p/s @ 12 bit Sensitivity mode

0.5 e-/p/s @ 12 bit Super sensitivity mode
Full Well Capacity: 15,000 e- @ 16 bit HDR mode

1,000 e- / 15,000 e- @ 11 bit Speed mode

1,500 e- @ 12 bit Sensitivity mode

1,000 e- @ 12 bit Super sensitivity mode
Shutter Mode: Rolling
Image Correction: DPC
ROI: Support
Binning (FPGA): 2 x 2, 4 x 4
Cooling Method: Liquid Cooling , Air Cooling
Cooling Temperature: Air: 0 °C @ 25 °C ambient
Liquid: -10 °C @ 20 °C liquid temprature
Trigger Mode: Hardware, Software
Output Trigger Signals: Exposure start, Global, Readout end, Trigger ready, Global reset, First row, Any row
Trigger Interface: Hirose
SDK: C / C++ / C# / Python
Data Interface: 2x10G GigE
Optical Interface: C Mount
Power: 12 V / 8 A
Power Consumption: ≤ 55 W
Dimensions: 95 mm (H) x 100 mm (W) x 100 mm (L)
Camera Weight: 1350g
Operating System: Windows / Linux
Operating Environment: Working: Temperature 0~40 °C, Humidity 10~85 %

Storage: Temperature -10~60 °C, Humidity 0~85 %

Additional Details

  • Manufacturer: Tucsen
  • Model: Aries 6506 5.7MP Monochrome Cooled sCMOS
  • Catalog Number: Aries6506
  • Serial Number: N/A
  • Condition: New
