SKU: PRODUCT ID:51904
Tucsen Dhyana 400D 4.2MP Monochrome sCMOS Microscope Camera
Tucsen Dhyana 400D 4.2MP Monochrome sCMOS Microscope Camera
This is the Tucsen manufacturer list price.
Additional discounts may apply. Contact us for potential discount pricing and your exact quote.
Call (877) 564-2767 or email sales@coastalmicroscopes.com
Couldn't load pickup availability
- ✓ New, with the full manufacturer warranty
- ✓ Typical delivery in 1 to 3 weeks, depending on parts
- ✓ Prices shown exclude freight, insurance, tariffs and applicable taxes
- ✓ Installation, training and service available from our engineers (quoted separately)
- ✓ SAM.gov registered (CAGE 10ZU5). Purchase orders welcome
- ✓ Leasing and finance companies available
Questions? Call (877) 564-2767 or email sales@coastalmicroscopes.com
Tucsen Dhyana 400D 4.2MP Monochrome Cooled sCMOS Camera
Additional discounts may apply. Contact us for a quote.
The Tucsen Dhyana 400D is a cooled 4.2 megapixel monochrome sCMOS camera built on the Gpixel GSENSE2020 front-illuminated sensor, with 72% peak QE, 2 e- read noise and 6.5 µm pixels across an 18.8 mm diagonal. It is a practical, sensitive camera for routine and low-light fluorescence on research and core facility microscopes.
Condition
New with Manufacturer Warranty
Key Features
- 4.2 megapixel Gpixel GSENSE2020 sCMOS sensor, 2048 x 2040 array
- 72% peak quantum efficiency at 595 nm
- 2.0 e- read noise in High Gain mode
- 6.5 µm pixels, matched to 40x to 100x objectives
- 45 ke- full well and 86.6 dB dynamic range
- 35 fps at full resolution, 16-bit
- Forced-air cooling for low dark current (0.12 e-/pixel/s at -10 °C)
- Hardware 2 x 2 binning for extra sensitivity in low light
Applications
- Widefield fluorescence microscopy
- Live-cell imaging
- Bioluminescence and chemiluminescence imaging
- Calcium imaging
- Teaching and core facility microscopes
Specifications
| Manufacturer | Tucsen |
| Model | Dhyana 400D |
| Sensor | Gpixel GSENSE2020 front-illuminated sCMOS |
| Resolution | 2048 x 2040 (4.2 MP) |
| Pixel size | 6.5 x 6.5 µm |
| Sensor area | 13.3 x 13.3 mm (18.8 mm diagonal) |
| Peak QE | 72% at 595 nm |
| Read noise | 2.0 e- (High Gain) |
| Full well | 45 ke- (typical) |
| Dynamic range | 86.6 dB |
| Frame rate | 35 fps at 16-bit, full resolution |
| Shutter | Rolling |
| Cooling | Forced air |
| Dark current | 0.12 e-/pixel/s at -10 °C |
| Binning | 2 x 2 hardware binning |
| Interface | USB 3.0 |
| Lens mount | C-mount |
| Power | 12 V DC |
| Software | Tucsen Mosaic; Micro-Manager supported |
Additional Details
Additional Details
- Manufacturer: Tucsen
- Model:
- Catalog Number: 51904
- Serial Number: KBSH09725016
- Condition: New
